 Volume 8, Issue 1 (January 2021), Pages: 41-49

----------------------------------------------

 Original Research Paper

 Title: Simulation of glacial lake outburst flood hazard in Hunza valley of upper Indus Basin

 Author(s): Naseem Gilany 1, *, Javed Iqbal 1, Anwaar Ahmed 2

 Affiliation(s):

 1School of Civil and Environment Engineering, National University of Sciences and Technology, Islamabad, Pakistan
 2National Institute of Transportation, SCEE, NUST, Islamabad, Pakistan

  Full Text - PDF          XML

 * Corresponding Author.

  Corresponding author's ORCID profile: https://orcid.org/0000-0002-5241-9888

 Digital Object Identifier:

 https://doi.org/10.21833/ijaas.2021.01.006

 Abstract:

The UIB (Upper Indus Basin) is prone to GLOFs (Glacial Lake Outburst Floods). Physical monitoring of such a large area on a regular basis is a challenging task, especially when the temporal and spatial extent of the hazard is highly variable. The purpose of this study was to map the potentially dangerous glacial lakes and simulate the associated hazard in the downward settlements using HEC-RAS in the GIS environment using Landsat 7 remote sensing data. The study was conducted in Hunza Valley of UIB, where there are several human settlements that are endangered due to the GLOF hazard. Sudden breaches in the unstable moraine dams adjoining receding glaciers may occur because of the rapid and huge accumulation of turbulent water in the glacial lakes. The ASTER GDEM (Digital Elevation Model) is utilized to detect flow accumulation of glacial hazard involving slope, elevation, and orientation of the mountain glaciers. The study results revealed that settlements of Hunza Valley are threatened by the GLOFs hazard. Keeping in view the seasonal growth of the potentially dangerous glacial lakes of Hunza Valley, a low discharge of 3500m3/s from a potentially dangerous glacial lake can affect 40%, whereas a moderate discharge of 5000m3/s can affect 60%, and a high discharge of 7000m3/s can affect 80% of the Shimshal village habitat. The results of the study can provide a platform for the establishment of an early warning and monitoring system to minimize the impact of future GLOFs. Accurate and comprehensive knowledge of potentially dangerous GLOFs is of utmost importance for risk management. A digital repository of GLOFs can enhance the ability to inform policymakers on the vulnerability, risk mitigation, and action/adaptation measures.

 © 2020 The Authors. Published by IASE.

 This is an open access article under the CC BY-NC-ND license (http://creativecommons.org/licenses/by-nc-nd/4.0/).

 Keywords: Anthropogenic, Disastrous, Geo-morphology, Glacial lake outburst flood

 Article History: Received 13 May 2020, Received in revised form 23 August 2020, Accepted 25 August 2020

 Acknowledgment:

We are highly grateful to Almighty Allah, the most beneficent, the most merciful, for giving us strength, courage, and resources to complete this research. We are sincerely obliged to IGIS-NUST for providing us platform of a knowledge base during the study period. We are very thankful to SUPARCO for cooperation and help in this research work. We acknowledge PMD (Pakistan) for the provision of data support for this paper.

 Compliance with ethical standards

 Conflict of interest: The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

 Citation:

  Gilany N, Iqbal J, and Ahmed A (2021). Simulation of glacial lake outburst flood hazard in Hunza valley of upper Indus Basin. International Journal of Advanced and Applied Sciences, 8(1): 41-49

 Permanent Link to this page

 Figures

 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5

 Tables

 Table 1 Table 2 Table 3

----------------------------------------------

 References (45)

  1. Ali K, Bajracharya RM, Chapagain NR, Raut N, Sitaula BK, Begum F, and Ahmed A (2019). Analyzing land cover change using remote sensing and GIS: A case study of Gilgit river basin, North Pakistan. International Journal of Economic and Environmental Geology, 10(1): 100-105. https://doi.org/10.46660/ijeeg.Vol10.Iss1.2019.224   [Google Scholar]
  2. Ashraf A, Naz R, and Roohi R (2012). Glacial lake outburst flood hazards in Hindukush, Karakoram and Himalayan Ranges of Pakistan: Implications and risk analysis. Geomatics, Natural Hazards and Risk, 3(2): 113-132. https://doi.org/10.1080/19475705.2011.615344   [Google Scholar]
  3. Bashir F, Zeng X, Gupta H, and Hazenberg P (2017). A hydrometeorological perspective on the Karakoram anomaly using unique valley‐based synoptic weather observations. Geophysical Research Letters, 44(20): 10470-10478. https://doi.org/10.1002/2017GL075284   [Google Scholar]
  4. Bhambri R, Bolch T, Kawishwar P, Dobhal DP, Srivastava D, and Pratap B (2013). Heterogeneity in glacier response in the upper Shyok valley, northeast Karakoram. The Cryosphere, 7(5): 1385-1398. https://doi.org/10.5194/tc-7-1385-2013   [Google Scholar]
  5. Bhutiyani MR (1999). Mass-balance studies on Siachen glacier in the Nubra valley, Karakoram Himalaya, India. Journal of Glaciology, 45(149): 112-118. https://doi.org/10.1017/S0022143000003099   [Google Scholar]
  6. Bolch T, Kulkarni A, Kääb A, Huggel C, Paul F, Cogley JG, and Bajracharya S (2012). The state and fate of Himalayan glaciers. Science, 336(6079): 310-314. https://doi.org/10.1126/science.1215828   [Google Scholar] PMid:22517852
  7. Brunner GW (2002). HEC-RAS: River analysis system. In: Bathala C (Ed.), North American water and environment congress and destructive water: 3782-3787. American Society of Civil Engineers (ASCE), New York, USA.   [Google Scholar]
  8. Budhathoki KP, Bajracharya OR, and Pokharel BK (2010). Assessment of Imja Glacier Lake outburst flood (GLOF) risk in Dudh Koshi River Basin using remote sensing techniques. Journal of Hydrology and Meteorology, 7(1): 75-91. https://doi.org/10.3126/jhm.v7i1.5618   [Google Scholar]
  9. Che T, Xiao L, and Liou YA (2014). Changes in glaciers and glacial lakes and the identification of dangerous glacial lakes in the Pumqu River Basin, Xizang (Tibet). Advances in Meteorology, 2014: 903709. https://doi.org/10.1155/2014/903709   [Google Scholar] PMid:28845079
  10. Costa JE (1988). Rheologic, geomorphic and sedimentologic differentiation of water floods, hyperconcentrated flows and debris flows. In: Baker VR, Kochel RC, and Patton PC (Eds.), Flood geomorphology: 113-122. John Wiley and Sons, New York, USA.   [Google Scholar]
  11. Das L and Meher JK (2019). Drivers of climate over the Western Himalayan region of India: A review. Earth-Science Reviews, 198: 102935. https://doi.org/10.1016/j.earscirev.2019.102935   [Google Scholar]
  12. Din K, Tariq S, Mahmood A, and Rasul G (2014). Temperature and precipitation: GLOF triggering indicators in Gilgit-Baltistan, Pakistan. Pakistan Journal of Meteorology, 10(20): 39-56.   [Google Scholar]
  13. Geerken HH and Bräker A (2017). The Karakoram highway and the Hunza Valley, 1998: History, culture, experiences. BoD–Books on Demand, Norderstedt, Germany.   [Google Scholar]
  14. Gilany N and Iqbal J (2020). Geospatial analysis and simulation of glacial lake outburst flood hazard in Shyok Basin of Pakistan. Environmental Earth Sciences, 79: 139. https://doi.org/10.1007/s12665-020-8867-y   [Google Scholar]
  15. Gilany SNA and Iqbal J (2016). Geospatial analysis of glacial hazard prone areas of Shigar and Shayok basins. International Journal of Innovation and Applied Studies, 14: 623-644.   [Google Scholar]
  16. Goudie AS, Brundsden D, Whalley W, Collins D, and Derbyshire E (1984). The geomorphology of the Hunza valley, Karakoram mountains, Pakistan. In The International Karakoram Project: International Conference, Cambridge University Publisher, Cambridge, UK: 359-410.   [Google Scholar]
  17. Hambrey MJ, Quincey DJ, Glasser NF, Reynolds JM, Richardson SJ, and Clemmens S (2008). Sedimentological, geomorphological and dynamic context of debris-mantled glaciers, Mount Everest (Sagarmatha) region, Nepal. Quaternary Science Reviews, 27(25-26): 2361-2389. https://doi.org/10.1016/j.quascirev.2008.08.010   [Google Scholar]
  18. Harrison S, Kargel JS, Huggel C, Reynolds J, Shugar DH, Betts RA, and Reinhardt L (2018). Climate change and the global pattern of moraine-dammed glacial lake outburst floods. The Cryosphere, 12(4): 1195-1209. https://doi.org/10.5194/tc-12-1195-2018   [Google Scholar]
  19. Hewitt K (1998). Recent glacier surges in the Karakoram Himalaya, South Central Asia. American Geophysical Union, Washington, USA. https://doi.org/10.1029/98EO00071   [Google Scholar]
  20. Huggel C, Kääb A, Haeberli W, Teysseire P, and Paul F (2002). Remote sensing based assessment of hazards from glacier lake outbursts: A case study in the Swiss Alps. Canadian Geotechnical Journal, 39(2): 316-330. https://doi.org/10.1139/t01-099   [Google Scholar]
  21. Immerzeel WW, Van Beek LP, and Bierkens MF (2010). Climate change will affect the Asian water towers. Science, 328(5984): 1382-1385. https://doi.org/10.1126/science.1183188   [Google Scholar] PMid:20538947
  22. Isserman M, Weaver SA, and Molenaar D (2010). Fallen giants: A history of Himalayan mountaineering from the age of empire to the age of extremes. Yale University Press, London, UK.   [Google Scholar]
  23. Iturrizaga L (2005). Historical glacier-dammed lakes and outburst floods in the Karambar valley (Hindukush-Karakoram). GeoJournal, 63(1-4): 1-47. https://doi.org/10.1007/s10708-005-2395-x   [Google Scholar]
  24. Kaushik S, Joshi PK, and Singh T (2019). Development of glacier mapping in Indian Himalaya: A review of approaches. International Journal of Remote Sensing, 40(17): 6607-6634. https://doi.org/10.1080/01431161.2019.1582114   [Google Scholar]
  25. Khan SAR, Jian C, Zhang Y, Golpîra H, Kumar A, and Sharif A (2019). Environmental, social and economic growth indicators spur logistics performance: From the perspective of South Asian Association for Regional Cooperation countries. Journal of Cleaner Production, 214: 1011-1023. https://doi.org/10.1016/j.jclepro.2018.12.322   [Google Scholar]
  26. Kreutzmann H, Abdulalishoev K, Zhaohui L, and Richter J (2011). Pastoralism and rangeland management in mountain areas in the context of climate and global change. In the Regional Workshop in Khorog and Kashgar, Deutsche Gesellschaft für Internationale Zusammenarbeit (GIZ), Bonn, Germany.   [Google Scholar]
  27. Kreutzmann, H. (2018). Language variegation across the Pamir Hindukush-Karakoram. Südasien-Chronik-South Asia Chronicle, 7: 251-273.   [Google Scholar]
  28. Lala JM (2018). Modeling and risk assessment of glacial lake outburst floods (GLOFs): A case study of Imja Tsho in the Nepal Himalayas. Ph.D. Dissertation, University of Texas at Austin, Austin, USA.   [Google Scholar]
  29. Mayer C, Lambrecht A, Belo M, Smiraglia C, and Diolaiuti G (2006). Glaciological characteristics of the ablation zone of Baltoro glacier, Karakoram, Pakistan. Annals of Glaciology, 43: 123-131. https://doi.org/10.3189/172756406781812087   [Google Scholar]
  30. Mertes JR, Thompson SS, Booth AD, Gulley JD, and Benn DI (2017). A conceptual model of supra‐glacial lake formation on debris‐covered glaciers based on GPR facies analysis. Earth Surface Processes and Landforms, 42(6): 903-914. https://doi.org/10.1002/esp.4068   [Google Scholar]
  31. Mir RA, Jain SK, Lohani AK, and Saraf AK (2018). Glacier recession and glacial lake outburst flood studies in Zanskar basin, western Himalaya. Journal of Hydrology, 564: 376-396. https://doi.org/10.1016/j.jhydrol.2018.05.031   [Google Scholar]
  32. Mool PK, Wangda D, Bajracharya SR, Kunzang KARMA, Gurung DR, and Joshi SP (2001). Inventory of glaciers, glacial lakes and glacial lake outburst floods: Monitoring and early warning systems in the Hindu Kush-Himalayan Region: Bhutan. Centre for Agriculture and Bioscience International, Wallingford, UK.   [Google Scholar]
  33. Mukhopadhyay B and Khan A (2015). A reevaluation of the snowmelt and glacial melt in river flows within Upper Indus Basin and its significance in a changing climate. Journal of Hydrology, 527: 119-132. https://doi.org/10.1016/j.jhydrol.2015.04.045   [Google Scholar]
  34. Nabi G, Ullah S, Khan S, Ahmad S, and Kumar S (2018). China-Pakistan Economic Corridor (CPEC): Melting glaciers-A potential threat to ecosystem and biodiversity. Environmental Science and Pollution Research, 25(4): 3209-3210. https://doi.org/10.1007/s11356-017-1151-3   [Google Scholar] PMid:29290058
  35. Nie Y, Liu Q, Wang J, Zhang Y, Sheng Y, and Liu S (2018). An inventory of historical glacial lake outburst floods in the Himalayas based on remote sensing observations and geomorphological analysis. Geomorphology, 308: 91-106. https://doi.org/10.1016/j.geomorph.2018.02.002   [Google Scholar]
  36. Osti R and Egashira S (2009). Hydrodynamic characteristics of the Tam Pokhari Glacial Lake outburst flood in the Mt. Everest region, Nepal. Hydrological Processes: An International Journal, 23(20): 2943-2955. https://doi.org/10.1002/hyp.7405   [Google Scholar]
  37. Quincey DJ, Glasser NF, Cook SJ, and Luckman A (2015). Heterogeneity in Karakoram glacier surges. Journal of Geophysical Research: Earth Surface, 120(7): 1288-1300. https://doi.org/10.1002/2015JF003515   [Google Scholar]
  38. Rankl M, Kienholz C, and Braun M (2014). Glacier changes in the Karakoram region mapped by multimission satellite imagery. The Cryosphere, 8(3): 977-989. https://doi.org/10.5194/tc-8-977-2014   [Google Scholar]
  39. Raup B, Kääb A, Kargel JS, Bishop MP, Hamilton G, Lee E, and Beedle M (2007). Remote sensing and GIS technology in the global land ice measurements from space (GLIMS) project. Computers and Geosciences, 33(1): 104-125. https://doi.org/10.1016/j.cageo.2006.05.015   [Google Scholar]
  40. Shah AA and Kanth TAG (2012). Impact of glaciers on the hydrology of Kashmir Rivers: A case study of Kolahoi Glacier. An unpublished M Phil Dissertation, Department of Geography and Regional Development, University of Kashmir, Kashmir, Pakistan.   [Google Scholar]
  41. Singh SP, Bassignana-Khadka I, Singh Karky B, and Sharma E (2011). Climate change in the Hindu Kush-Himalayas: The state of current knowledge. International Centre for Integrated Mountain Development (ICIMOD), Patan, Nepal.   [Google Scholar]
  42. Singh UP (2015). A study of Sino-Indian border issues. Research Review International Journal of Multidisciplinary, 2(9): 119-123.   [Google Scholar]
  43. Stäubli A, Nussbaumer SU, Allen SK, Huggel C, Arguello M, Costa F, and Zambrano E (2018). Analysis of weather-and climate-related disasters in mountain regions using different disaster databases. In: Mal S, Singh R, and Huggel C (Eds.), Climate change, extreme events and disaster risk reduction: 17-41. Springer, Cham, Switzerland. https://doi.org/10.1007/978-3-319-56469-2_2   [Google Scholar]
  44. Steiner JF, Kraaijenbrink PD, Jiduc SG, and Immerzeel WW (2018). Brief communication: The Khurdopin glacier surge revisited-Extreme flow velocities and formation of a dammed lake in 2017. Cryosphere, 12(1): 95-101. https://doi.org/10.5194/tc-12-95-2018   [Google Scholar]
  45. Wang S and Zhou L (2017). Glacial lake outburst flood disasters and integrated risk management in China. International Journal of Disaster Risk Science, 8(4): 493-497. https://doi.org/10.1007/s13753-017-0152-7   [Google Scholar]
